Mitsubishi GOT2000 Series Connection Manual

8. BUS CONNECTION
8.2 System Configuration
8 - 15
8
BUS CONNECTION
*1 For details on the extension cables, refer to the MELSEC-A/QnA catalog (L(NA)8024).
*2 When installing the GOT 30m or more away from the main base unit, the bus connector conversion box is required.
*3 When using GT15-C EXSS-1, connect as the following precautions.
8.4.1 GT15-C [ ] EXSS-1, GT15-C [ ] BS
*4 When using the following functions, use GT15-QBUS(2). GT15-75QBUS(2)L cannot be used.
Remote personal computer operation (Serial), video display function, multimedia function, external I/O device, RGB display
function, sound output function
Extens
ion
base
Extension
cable
Main
base
--
GT15-A1SC07B(0.7m)
GT15-A1SC12B(1.2m)
GT15-A1SC30B(3m)
GT15-A1SC50B(5m)
GT15-75ABUSL
GT15-
75ABUS2L
GT15-ABUS
GT15-ABUS2
Between extension base
and GOT: 6m
(Including the extension
cable length)
--
GT15-C100EXSS-
1(10m)
GT15-C200EXSS-
1(20m)
GT15-C300EXSS-
1(30m)
*3
GT15-75ABUSL
GT15-
75ABUS2L
GT15-ABUS
GT15-ABUS2
Between extension base
and GOT: 36m
(Including the extension
cable length)
GT15-A1SC05NB(0.45m)
GT15-A1SC07NB(0.7m)
GT15-A1SC30NB(3m)
GT15-A1SC50NB(5m)
A7GT
-CNB
GT15-C100EXSS-
1(10m)
GT15-C200EXSS-
1(20m)
GT15-C300EXSS-
1(30m)
*3
GT15-75ABUSL
GT15-
75ABUS2L
GT15-ABUS
GT15-ABUS2
Between extension base
and GOT: 36m
Between extension base
and bus connector
conversion box: 6m
(Including the extension
cable length)
PLC
Connection cable 2)
GOT
Max. distance
Extens
ion
base
Extension
cable
*1
Main
base
Connection cable 1)
Bus
connector
conversion
box
*2
Option device
*4
Model

Mitsubishi GOT2000 Series Specifications

General

Power Supply	24VDC
Software	GT Works3
Processor	RISC CPU
Interface	Ethernet, USB, RS-232, RS-422/485
Operating Temperature	0°C to 50°C
Display Type	TFT LCD
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s² (15G), 11ms duration
Touch Panel	Analog Resistive
