8. BUS CONNECTION
8.2 System Configuration
8 - 17
8
BUS CONNECTION
*6 About the bus connection unit
GT15-75ABUSL, GT15-ABUS: Used for a terminal GOT. (Not available for an intermediary GOT)
GT15-75ABUS2L, GT15-ABUS2: Used for an intermediary GOT. (Can be used for a terminal GOT)
*7 When using the following functions, use GT15-QBUS(2). GT15-75QBUS(2)L cannot be used.
Remote personal computer operation (Serial), video display function, multimedia function, external I/O device, RGB display
function, sound output function
Connection cable 3)
GOT (2nd)
*3*5
Max. distance
Option device
*6*7
Model
GT15-C07BS(0.7m)
GT15-C12BS(1.2m)
GT15-C30BS(3m)
GT15-C50BS(5m)
GT15-C100BS(10m)
GT15-C200BS(20m)
GT15-C300BS(30m)
*4
GT15-75ABUSL
GT15-75ABUS2L
GT15-ABUS
GT15-ABUS2
Between main base and GOT(1st): 5m
Between GOT (1st) and GOT (2nd): 30m
Between main base and GOT (2nd): 35m
GT15-75ABUSL
GT15-75ABUS2L
GT15-ABUS
GT15-ABUS2
Between main base and GOT (2nd): 30m
GT15-75ABUSL
GT15-75ABUS2L
GT15-ABUS
GT15-ABUS2
Between main base and bus connector conversion box: 5m
Between bus connector conversion box and GOT (2nd): 30m
Between main base and GOT (2nd): 35m
GT15-C07BS(0.7m)
GT15-C12BS(1.2m)
GT15-C30BS(3m)
GT15-C50BS(5m)
GT15-C100BS(10m)
GT15-C200BS(20m)
GT15-C300BS(30m)
*4
GT15-75ABUSL
GT15-75ABUS2L
GT15-ABUS
GT15-ABUS2
Between extension base and GOT (1st): 6m (Including the extension cable length)
Between GOT (1st) and GOT (2nd): 30m
Between extension base and GOT (2nd): 36m (Including the extension cable length)
GT15-75ABUSL
GT15-75ABUS2L
GT15-ABUS
GT15-ABUS2
Between main base and GOT (2nd): 30m
Between extension base and GOT (2nd): 36m (Including the extension cable length)
GT15-75ABUSL
GT15-75ABUS2L
GT15-ABUS
GT15-ABUS2
Extension base and bus connector conversion box: 6m (Including extension cable length)
Between bus connector conversion box and GOT (2nd): 30m
Between extension base and GOT (2nd): 36m (Including the extension cable length)
