Mitsubishi GOT2000 Series Connection Manual

8. BUS CONNECTION
8.2 System Configuration
8 - 31
8
BUS CONNECTION
*5 When using GT15-C BS, connect as following precautions.
8.4.1 GT15-C [ ] EXSS-1, GT15-C [ ] BS
*6 The bus connection unit
GT15-75ABUSL, GT15-ABUS: Used for a terminal GOT. (Not available for an intermediary GOT)
GT15-75ABUS2L, GT15-ABUS2: Used for an intermediary GOT. (Can be used for a terminal GOT)
*7 When using the following functions, use GT15-QBUS(2). GT15-75QBUS(2)L cannot be used.
Remote personal computer operation (Serial), video display function, multimedia function, external I/O device, RGB display
function, sound output function
Connection cable 3)
GOT (2nd)
*3*4
Connection cable 4)
GOT (3rd)
*3*4
Max. distance
Option device
*6*7
Model
Option device
*6*7
Model
GT15-C07BS(0.7m)
GT15-C12BS(1.2m)
GT15-C30BS(3m)
GT15-C50BS(5m)
GT15-C100BS(10m)
GT15-C200BS(20m)
*5
GT15-75ABUS2L
GT15-ABUS2
GT15-C07BS(0.7m)
GT15-C12BS(1.2m)
GT15-C30BS(3m)
GT15-C50BS(5m)
GT15-C100BS(10m)
GT15-C200BS(20m)
*5
GT15-75ABUSL
GT15-75ABUS2L
GT15-ABUS
GT15-ABUS2
Between main base and GOT(1st): 3m
Between GOT (1st) and GOT (3rd): 30m
Between main base and GOT (3rd): 33m
GT15-C07BS(0.7m)
GT15-C12BS(1.2m)
GT15-C30BS(3m)
GT15-C50BS(5m)
GT15-C100BS(10m)
GT15-C200BS(20m)
*5
GT15-75ABUS2L
GT15-ABUS2
GT15-C07BS(0.7m)
GT15-C12BS(1.2m)
GT15-C30BS(3m)
GT15-C50BS(5m)
GT15-C100BS(10m)
GT15-C200BS(20m)
*5
GT15-75ABUSL
GT15-75ABUS2L
GT15-ABUS
GT15-ABUS2
Between main base and GOT(1st): 3m
(Including the extension cable length)
Between GOT (1st) and GOT (3rd): 30m
Between main base and GOT (3rd): 33m
(Including the extension cable length)
Communication driver
Bus(A/QnA)

Mitsubishi GOT2000 Series Specifications

General

Power Supply	24VDC
Software	GT Works3
Processor	RISC CPU
Interface	Ethernet, USB, RS-232, RS-422/485
Operating Temperature	0°C to 50°C
Display Type	TFT LCD
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s² (15G), 11ms duration
Touch Panel	Analog Resistive
