1 - 6
1. PREPARATORY PROCEDURES FOR MONITORING
1.1 Setting the Communication Interface
(2) Setting [Controller Type]
The types for the selection differs depending on the PLC to be used.
For the settings, refer to the following.
*1 When using the multiple CPU system
When using the GOT to monitor the multiple CPU system of
other station, select [MELSEC-Q(Multi)/Q-Motion], or
[MELSEC-QnU/DC,Q17nD/M/NC/DR,CRnD-700] for the
type regardless of the host PLC CPU type.
*2 When connecting to the remote I/O station in the MELSECNET/
H network system, set the type to [MELSECQnA/Q/QS,
MELDAS C6 *].
Type Model name
MELSEC-Q/QS, Q17nD/M/NC/DR, CRnD-700
Q00CPU
Q01CPU
Q02CPU
Q02HCPU
Q06HCPU
Q12HCPU
Q25HCPU
Q02PHCPU
Q06PHCPU
Q12PHCPU
Q25PHCPU
Q172CPU
Q173CPU
Q172CPUN
Q173CPUN
Q172HCPU
Q173HCPU
Q00UJCPU
Q00UCPU
Q01UCPU
Q02UCPU
Q03UDCPU
Q04UDHCPU
Q06UDHCPU
Q10UDHCPU
Q13UDHCPU
Q20UDHCPU
Q26UDHCPU
Q03UDECPU
Q04UDEHCPU
Q06UDEHCPU
Q10UDEHCPU
Q13UDEHCPU
Q20UDEHCPU
Q26UDEHCPU
Q50UDEHCPU
Q100UDEHCPU
Q03UDVCPU
Q04UDVCPU
Q06UDVCPU
Q13UDVCPU
Q26UDVCPU
Q04UDPVCPU
Q06UDPVCPU
Q13UDPVCPU
Q26UDPVCPU
Q12DCCPU-V
Q24DHCCPU-V
Q24DHCCPU-LS
Q172DCPU
Q173DCPU
Q172DCPU-S1
Q173DCPU-S1
Q172DSCPU
Q173DSCPU
Q170MCPU
Q170MSCPU
Q170MSCPU-S1
MELSEC-Q/QS, Q17nD/M/NC/DR, CRnD-700
CNC C70
(Q173NCCPU)
CRnQ-700
(Q172DRCPU)
CR750-Q
(Q172DRCPU)
CR751-Q
(Q172DRCPU)
CRnD-700
CR750-D
CR751-D
MELSEC-QnA, MELDAS C6*
Q00JCPU
Q00CPU
Q01CPU
Q02CPU
Q02HCPU
Q06HCPU
Q12HCPU
Q25HCPU
Q02PHCPU
Q06PHCPU
Q12PHCPU
Q25PHCPU
Q12PRHCPU
Q25PRHCPU
QS001CPU
Q2ACPU
Q2ACPU-S1
Q3ACPU
Q4ACPU
Q4ARCPU
Q2ASCPU
Q2ASCPU-S1
Q2ASHCPU
Q2ASHCPU-S1
MELDAS C6
(FCA C6)
MELDAS C64
(FCA C64)
MELSEC-L
L02CPU
L06CPU
L26CPU
L26CPU-BT
L02CPU-P
L06CPU-P
L26CPU-P
L26CPU-PBT
L02SCPU
L02SCPU-P
NZ2GF-ETB
Type Model name
