15. SERVO AMPLIFIER CONNECTION
15.2 System Configuration
 When connecting to multiple servo amplifiers (RS-422 connection)
*1 Connect the connector of the servo amplifier to CN3.
*2 The distributor is a product manufactured by HAKKO ELECTRIC CO., LTD. For details, contact HAKKO ELECTRIC CO., LTD.
GOTDistributor
Connection cable 3)Connection cable 2) Terminal cable
Connection cable 1)
Distributor
Connection cable 1)
Servo
amplifier
Servo
amplifier
Communication driver
MELSERVO-J4, J3, J2S/M, JE
Servo amplifier
Terminating
cable
Connection
cable
1)
Distributor
*2
Connection
cable
2)
Distributor
*2
Connection
cable
3)
GOT
Max.
dista
nce
Number of
connectable
equipment
Series name
Commu
nication
type
Connection
diagram
number
Connection
diagram
number
Model
name
Connection
diagram
number
Model
name
Connection
diagram
number
Option device Model
MELSERVO
-J4
*1
, J3
*1
RS-422
RS422
connection
diagram 5)
RS422
connection
diagram 4)
BMJ-8
(Recomm
ended)
RS422
connection
diagram 3)
BMJ-8
(Recomm
ended)
RS422
connection
diagram 2)
- (Built into
GOT)
30m
Up to 32
axes for
1 GOT
GT15-RS4-9S

Mitsubishi GOT2000 Series Specifications

General

Power Supply	24VDC
Software	GT Works3
Processor	RISC CPU
Interface	Ethernet, USB, RS-232, RS-422/485
Operating Temperature	0°C to 50°C
Display Type	TFT LCD
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s² (15G), 11ms duration
Touch Panel	Analog Resistive
