• Installation direction of the driven pulley shaft is specified.Thin shaft side faces down.
Also refer to " " p.10-4.
• After installing the CR driven pulley, move the carriage with your hand from side to side, and
check if the CR belt is equally balanced on the pulley center section of the CR motor assembly.
8. Perform adjustments by following the instructions in "7.2 Adjustment Item" p.7-3.
