ValueJet 1304　Service manual
AP-74109 Rev 1.1 5-8
5.3.2 Diagnosis Items in Self-Diagnosis Menu
The self-diagnosis menu includes the following diagnosis items.
Diagnosis item Contents Reference
Platen Adjustment
Menu
Performs temperature setting for the pre-heater and platen
heater to 30 °C.
"5.4 Platen
Adjustment Menu"
p.5-10
Inspection Menu Performs various inspections on the memory, version,
operation panel, sensors, encoders, fans, and head waveform.
Also, displays the inspection records of above items.
"5.5 Inspection
Menu" p.5-11
Ink Charging Menu Performs ink charging. "5.6 Ink
Charging Menu"
p.5-22
Adjustment Menu Performs various adjustments for the printer mechanism. "5.7
Adjustment Menu"
p.5-23
Cleaning Menu Performs cleaning of the print head. "5.7.11 Feed
Pitch Check Menu"
p.5-46
Print Menu Performs sample printing necessary for adjustment. "5.9 Sample
Printing Menu" p.5-
49
Time Check Menu Confirming the time of the printer. "5.10 Time
Check" p.5-52
Parameter Menu Configures various adjustment parameters. "5.11
Parameter Menu"
p.5-52
Servo Menu Performs adjustment for the servo motor. "5.12 Servo
Setting" p.5-64
Endurance Running
Menu
Performs endurance running of the printer mechanism. "5.13
Endurance Running
Menu" p.5-67
Media feed Menu Feeds media into the printer forward or backward. "5.14 Media
Feed Menu" p.5-73
ExControl Menu Diagnoses the controller board, sensors, heater check.
Also, displays the diagnosed records of above items.
"5.15 ExControl
Menu" p.5-74
PaperInitial Menu Performs initialization and media detection setting. "5.16
PaperInitial Menu"
p.5-77
