ValueJet 1304　Service manual
AP-74109 Rev 1.1 5-28
5.7.3 Skew Check Menu
Feed the paper to check the skew size using sensor.
When you select this item from the Adjustment Menu, the printer feeds the loaded media by one pass and
checks difference of the media edge positions before and after the media feed detected by the sensor.
Before performing skew check, ensure that the media is set correctly.
The printer determines the media setting reference position during first detection of media left edge.
Therefore, the media that is not set correctly may cause errors as below.
• Media error occurs during skew check and printer operation stops.
• During media initial operation after power is turned on or media is cut, "Undefined Paper"
frequently occurs.
Table 5-5 Skew Amount Specification
Condition Specification
Roll media 7 m 2.5 mm or less
To Next Page
