ValueJet 1304 Service manual
8-3 AP-74109 Rev 1.1
8.2 Periodical Services
This section describes the periodical services required for this printer.
The periodical services ensures stable plotting quality of the printer.
Follow the explanations below to perform periodical inspections necessary.
• Operation manual
• Separate sheet “Exploded view” P.2-P.10
8.2.1 Periodical Replacement Parts
The parts shown below need to be replaced per year.
Table 8-1 Parts to be replaced
Maintenance part name
(Maintenance part no.)
Part to be replaced Reference
VJ13 periodical replacement kit
(DG-41152)
Damper assembly "4.6.1 Replacing
Print Head" p.4-61
Maintenance assembly "4.7 Replacement of
Maintenance Section
Components" p.4-71
Cleaner head assembly "4.7.3 Replacing
Cleaner Head (Cleaning
Wiper)" p.4-77
To Next Page
