ValueJet 1304　Service manual
5-23 AP-74109 Rev 1.1
5.7 Adjustment Menu
In this menu, you can align the printing position and correct the media feed operation.
The adjustment menu includes the following diagnosis menus.
Table 5-4 Diagnosis Items in Adjustment Menu
Diagnosis item Contents Reference
CR return position
adjustment
Performs confirmation of the CR return position while
printing and adjustment.
Head nozzle check Prints out a printing to check the ink discharge
performance of the head nozzles.
"5.7.2 Head Nozzle
Check Menu" p.5-26
Skew check Performs media feed and detects the degree of skew in
media feed by the sensor.
"5.7.3 Skew Check
Menu" p.5-28
Head slant check Prints out a printing to check for print head slant
(horizontal and vertical direction). Mechanical
adjustment must be performed as necessary.
"5.7.4 Head Slant
Check Menu" p.5-29
Volt. Offset Adjusts the print position of VSD3 - small head. "5.7.5 Voltage
Adjustment" p.5-33
Uni-D / Bi-D
adjustment Low
Prints out a printing to align the nozzle line distance
(Uni-D) of PG Low and the position of the repeated
printing.
Uni-D 240: 240 cps
Uni-D 320: 320 cps
Uni-D 240B: 240cps Banner
Uni-D 320B: 320cps Banner
Bi-D 240: 240 cps
Bi-D 320: 320 cps
Bi-D 240B: 240cps Banner
Bi-D 320B: 320cps Banner
"5.7.6 Uni-D / Bi-D
Low and High
Adjustment" p.5-36
Uni-D / Bi-D
adjustment High
Prints out a printing to align the nozzle line distance
(Uni-D) of PG High and the position of the repeated
printing.
Uni-D 240: 240 cps
Uni-D 320: 320 cps
Uni-D 240B: 240cps Banner
Uni-D 320B: 320cps Banner
Bi-D 240: 240 cps
Bi-D 320: 320 cps
Bi-D 240B: 240cps Banner
Bi-D 320B: 320cps Banner
"5.7.6 Uni-D / Bi-D
Low and High
Adjustment" p.5-36
Side margin
adjustment
Sets the side margin. "5.7.7 Side Margin
Adjustment Menu" p.5-
42
Test printing Prints out a head nozzle check pattern, an adjustment
pattern, adjustment parameters, serious error history or a
dot pattern.
"5.7.8 Test Printing
Menu" p.5-43
To Next Page
