MUTOH ValueJet User Manual

ValueJet 1304 Service manual
AP-74109 Rev 1.1 9-14
NOTE
For the PC settings, refer to your PC's operation manual.
(2) Mechanical Serious Errors
Table 9-5 Symptoms and Check Items for Mechanical Serious Errors
No. Message Event/
symptom
Check item Action Reference
1 E 065 error
PF motor
Abnormal
condition in PF
motor (X-axis)
during printer
operation.
Displayed if
the difference
between motor
command
value and
feedback from
encoder is
large.
1. Check error history
from "Test7:
Record." of self-
diagnosis function.
2. Set the number of
endurance running
cycles to 50 or more
from “Check10:
Endurance” of
"Life2: PF Motor"
of self-diagnosis
function, and check
if "X motor error"
occurs.
3. Check "Encoder:
PF" from "Test5:
Encoder" of self-
diagnosis function.
4. PF motor assembly
may be defective.
5. Main board
assembly may be
defective.
-
Check connection of
following main board
assembly connectors.
•PF motor cable
assembly
connector: J20
• PF_ENC assembly
connector: J12
• If NG, check
connection of main
board assembly
connector: J12.
• Replace PF motor
assembly.
•Replace main board
assembly.
"5.5.7
History
Menu" p.5-18
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
"4.4.1
Replacing PF
Motor
Assembly"
p.4-44
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
