ValueJet 1304 Service manual
AP-74109 Rev 1.1 7-48
7.11.2 P_REAR Sensor Adjustment
(1) Jigs and Tools
The following jigs and tools are required for P_REAR sensor adjustment.
• Test media: MF-3G (A4)
TIP
"10.3 Jigs and Tools" p.10-3
(2) Adjustment Procedure
To adjust the P_REAR sensor, follow the steps below.
1. Sets the standard media.
2. Start up the self-diagnosis function.
TIP
"5.2.2 Starting Up" p.5-5
3. Select “Check: Test” from the self-diagnosis menu.
4. Select “Test: Sensor” from the inspection menu.
5. Select “Sen: Rear” from the sensor menu.
6. Open the front cover.
