ValueJet 1304　Service manual
AP-74109 Rev 1.1 5-68
5.13.1 CR Motor Endurance Menu
This menu performs endurance running for the CR motor.
You can operate the carriage stroke according to your desired settings. The available settings are shown
below.
When the CR motor endurance running is performed, note the following;
• Install available ink cartridges.
If the CR motor endurance running is performed without ink cartridges, ink inside the tube
may leak through the ink holder during the carriage movement.
• If the number of endurance running cycles is set to -1, the carriage continuously repeats endurance
running until cancel input is given from the operation panel.
• The maximum counter value for endurance running cycles is 99999999 (up to 8-digit number). If the
number of cycles exceeds the maximum value, the counter is reset to 0.
• The carriage moving distance is fixed to the maximum value of print area.
Table 5-19 Set Items in CR Motor Endurance Menu
Set item Contents Set value Remark
Running speed (CW,
CCW)
Set the carriage running speed
(CW direction, CCW direction)
100, 120, 160, 200,
240, 320, 400
Unit: cps
Number of endurance
running cycles
Set the number of endurance
running cycles
-1 to 10000
To Next Page
