MUTOH ValueJet User Manual

ValueJet 1304 Service manual
10-3 AP-74109 Rev 1.1
10.3 Jigs and Tools
This section provides lists of jigs and tools required for service operations.
10.3.1 Required Tools
(1) Tools for Part Replacement
(2) Tools for Adjustment
Table 10-1 Tools for Part Replacement
No. Name Part number Remarks
1 Phillips driver No.2 Generic product More than 250mm shaft length is
recommended
2 Phillips driver No.2 Generic product Less than 50mm shaft length is
recommended
3 Phillips driver No.1 Generic product
4 Flat-head driver Generic product
5 Longnose plier Generic product
6 Tweezers Generic product
7 Hex wrench (opposite side:
6mm)
Optional stand
accessory (Generic
product)
Required only when disassembling legs
8 Tube cutter Generic product Required when cutting the tube
Table 10-2 Tools for Adjustment
No. Name Part number Remarks
1 Personal computer Generic product
2 Tension gauge Generic product Max. 10,000gf (100N) for measurement
3 Tension gauge Generic product Max. 5,000gf (50N) for measurement

MUTOH ValueJet Specifications

General

Technology	Piezo Inkjet
Ink Type	Eco-solvent ink
Print Resolution	Up to 1440 dpi
Resolution	Up to 1440 dpi
Ink Colors	CMYK, White
Media Width	64 inches
Interface	USB, Ethernet
Operating Systems	Windows
