8.4 Lubrication/Bonding
This section covers the lubrication/bonding information.
After disassembling/assembling this printer, always perform necessary lubrication/bonding according to
Table 8-4"Lubricant List"(p.6).
CAUTION
Only use specified lubricants and greases. The use of unauthorized lubricants and greases
may damage the components and shorten the printer life.
Table 8-4 Lubricant List
Parts Item Manufacturer Type Exploded
view
Cover section Roll receiver
(L, R)
Apply to the top
cover contacting
surface.
Dow Corning
Toray Co.,Ltd.
MOLYKOTE
(R)EM-60L
GREASE
Front cover
support pin L
Apply to the top
cover contacting
surface.
Dow Corning
Toray Co.,Ltd.
MOLYKOTE
(R)EM-60L
GREASE
CR section Cursor guide Apply to the front
surface.
Mitsubishi Super multi-
dia tetrat
No.32
Pressure
shaft bearing
Apply to the
peripheral surface.
Dow Corning
Toray Co.,Ltd.
MOLYKOTE
(R)EM-60L
GREASE
Pressure
shaft stopper
Apply to the
pressure lever
springs.
Dow Corning
Toray Co.,Ltd.
MOLYKOTE
(R)EM-60L
GREASE
Head section Head cable Affix to each cable
(for locating and
holding)
Not specified 10mm- width
double faced
tape
Cable guide
section
CR cable Affix to each cable
(for locating)
Not specified 10mm-width
double faced
tape
Tube guide Affix to the tube
guide (for
locating)
Not specified 10mm-width
double faced
tape
Others Screw Apply to the area
screw-locking
agent is applied.
Three Bond
Co., Ltd.
1401 -
