8.2.2 Parts need to be checked or replaced
Table 8-2 Periodical Inspection Part List
Part Timing Check point Action
Media guide L
Sub platen front surface
Several times per
year
•Media dust
accumulation
• Foreign objects
• Damages
Clean it.
NOTE
If ink deposits
are present,
remove them
with a dampened
cloth and wipe
the area with a
clean dry cloth.
Timing fence
(CR encoder detection
slit plate)
Several times per
year
•Media dust
accumulation
• Foreign objects
• Damages
Clean it.
If any damages are found,
replace the part.
"4.5.4 Replacing T
Fence" p.4-55
Rail on the CR guide
frame
Several times per
year
Foreign objects Clean it.
P_REAR sensor front
surface
Several times per
year
•Media dust
accumulation
• Foreign objects
Clean it.
Cleaner head
(Cleaning wiper)
Several times per
year
• Ink deposits
• Damages
Clean it.
