MUTOH ValueJet User Manual

ValueJet 1304 Service manual
AP-74109 Rev 1.1 5-46
5.7.11 Feed Pitch Check Menu
In this menu, you can check the media feed amount for one band by reviewing a sample printing.There is no
adjustment items.
To check the feed pitch, follow the steps below.
1. Set media as necessary.
2. Select “Adj.: Send Pitch”.
3. Select the feed pitch.
• Pattern 1: Prints at intervals of 360 (720) dpi. This resolution causes no gaps.
• Pattern 2: Prints at intervals of 1440 dpi. This causes a gap in one line out of four lines.
4. Pattern 1 is printed as shown below.
A
A: Media feed direction
Media feed amount
for one band
[<] key
[<] key
[<] key
[<] key
[<] key
[<] key
[>] key
[>] key
[>] key
[>] key
[>] key
Finish Printing or [Cancel] key
[Enter] key

MUTOH ValueJet Specifications

General

Technology	Piezo Inkjet
Ink Type	Eco-solvent ink
Print Resolution	Up to 1440 dpi
Resolution	Up to 1440 dpi
Ink Colors	CMYK, White
Media Width	64 inches
Interface	USB, Ethernet
Operating Systems	Windows
