ValueJet 1304　Service manual
AP-74109 Rev 1.1 5-72
5.13.5 General Endurance Menu
This menu performs the general endurance running.
You can operate various driving systems according to your desired settings.
The available settings are shown below.
• In the general endurance menu, the following operations are performed as one cycle of endurance
running
• Carriage stroking: 1 stroke
• Media feed: 1 cycle
• If the number of endurance running cycles is set to -1, the carriage continuously repeats stroking
until cancel input is given from the operation panel.
• The maximum counter value for endurance running cycles is 99999999 (up to 8-digit number). If
the number of cycles exceeds the maximum value, the counter is reset to 0.
Table 5-23 Set Items in General Endurance Menu
Set item Contents Set value Remark
Running speed (CW,
CCW)
Set the carriage running
speed (CW direction,
CCW direction)
100, 120, 160, 200, 240m
320, 400
Unit: cps
Media feed amount Set the media feed
amount per cycle
0.1 to 100 Unit: mm
Number of endurance
running cycles
Set the number of
endurance running cycles
-1 to 10000
To Next Page
