ValueJet 1304　Service manual
AP-74109 Rev 1.1 3-2
3.1 Introduction
This chapter explains the specifications of the product, optional parts, and supplies. Installation environment
requirements are also explained.
3.2 Product Specifications
(1) Main Unit Specifications
Item Specifications
Model name
VJ-1304
Plotting method
On-demand piezo drive
Motor driving method
Firmware servo/DC motor drive
Media feeding method
Multi-point pressure grid roller method
Media fixing method
Pressurizing roller manual-down method
Media supply and
ejection
Roll media
Front feeding/front paper ejection
Media type
Tracing Paper
Roll media outer
diameter
2-inch
150 mm or less
Maximum
loadable media
weight
Roll media
19 kg (41.9 lb) or less
Maximum media width
1371.5 mm (54 in.)
Maximum media
length:
Roll media
50 m (160 ft.)
Maximum plot length
1355 mm (53.3 in.)
Plotting margins Roll media
Top: 3mm, Bottom: 3mm, Left: 3mm, Right: 3mm
Media cutting method
Manual cutting across the media
Head height adjustment
2 levels: Normal and High
Distance accuracy The larger value either ± 0.25 mm or ± 0.1% of moving distance
•Used media: Roll MF-3G
• Plot length: 1355.5 mm (4.45 ft.)
• Operating temperature: 22 to 30ºC (71.6 to 86F)
• Operating humidity: 40 to 60%
•PG: Low
• Plot mode: Graphics1
Right angle accuracy ±0.1mm or less against the moving distance (500.0mm)
•Used media: Roll MF-3G
• Operating temperature: 22 to 30ºC (71.6 to 86F)
• Operating humidity: 40 to 60%
• Plot mode: Graphics1
