ValueJet 1304 Service manual
AP-74109 Rev 1.1 5-42
5.7.7 Side Margin Adjustment Menu
This menu is used to adjust the printing margins.
To adjust the margins, follow the steps below.
1. Set media as necessary.
2. The printer detects the media size and the size is displayed on the operation panel.
3. The printer prints out band feed correction adjustment patterns and cuts the media in the following modes.
• Black, 1 pass, unidirectional, 360 dpi
* The pattern is printed with magenta if “Confirm” is selected.
4. Check the printed side margin adjustment patterns for the measurement.
1: Side margin
2: Media feed direction
5. Enter each measured value as the parameter.
(Input range: 0.0 to 6.0 mm (0.1 mm increments))
After pressing [Enter]key
After printing
Press [Setting/value+] or [Setting/value-] key
to select initialize or check
Side Margin: 0.1㨙㨙 increments
Press [Cancel] key to go back
to Adj8: SideMarginMenu
To Next Page
