ValueJet 1304　Service manual
3-3 AP-74109 Rev 1.1
CPU
64Bit RISC CPU
Memory
128MB
Command
MH-RTL (RTL-PASS)
Interface
Network Interface (IEEE802.3)
After-heater
OFF / 30 to 50°C (86 to 122F)
Platen heater
OFF / 30 to 50°C (86 to 122F)
Pre-heater
OFF / 30 to 50°C (86 to 122F)
Ink Supply method
Tube supply from separate four separated cartridges
Cartridge
Black, cyan, magenta, yellow: 220ml ± 5ml for each color
Head life expectancy
60 billion dots per nozzle (in case of sequence discharging under the condition
of the temperature of 25
ºC (77F) with no dust)
Environmental conditions
Operation environment
Temperature: 20ºC (68F) to 32ºC (90F)
Humidity: 40% to 60%, with no condensation
Plotting accuracy warranty range
Temperature: 22ºC (71.6F) to 30ºC (86F)
Humidity: 40% to 60%, with no condensation
Rate of change
Temperature: 2ºC/hour or less
Humidity: 5%/hour or less
Storage
environment
Without ink
Temperature: -20ºC (-4F) to 60ºC (140F)
Humidity: 20% to 80%, with no condensation
Storage period: 6 months
With ink
Temperature: -10ºC (14F) to 40ºC (104F)
Humidity: 20% to 80%, with no condensation
Storage period: 6 months
Power source Voltage
AC 90 - 132V ± 10%
Frequency
50Hz/60Hz ± 1Hz
Power
consumption
During Plotting 1260W or less (when heater is ON)
During standby 40W or less (when standby heater is OFF)
Outer dimensions Height
1218mm (48 in.) * including stand
Width
1875 mm (73.8 in.)
Depth
685 mm (27 in.)
Weight Main body
58.0 kg (127.8 lb.)
Stand
21.3 kg (46.9 lb)
Item Specifications
