ValueJet 1304 Service manual
4-79 AP-74109 Rev 1.1
NOTE
To remove the wiper, use the tweezers to unhook the lower hook of the wiper.
2. Replace the cleaner head.
3. To reassemble the unit, reverse the removal procedure.
NOTE
When removing the cleaner head, note the following.
• Do not touch the cleaner head with your bare hands.
• Make sure that the cleaner head get no dust or oil.
• Install the cleaner head so that the point of the cleaner head is located to the observer's right side.
• Insert the cleaner head into the holder to the full depth securely and hook it.
表 4-91
No. Part name
1 Cleaner head
2
Head point
Hook
1
2

MUTOH ValueJet Specifications

General

Technology	Piezo Inkjet
Ink Type	Eco-solvent ink
Print Resolution	Up to 1440 dpi
Resolution	Up to 1440 dpi
Ink Colors	CMYK, White
Media Width	64 inches
Interface	USB, Ethernet
Operating Systems	Windows
