ValueJet 1304 Service manual
4-87 AP-74109 Rev 1.1
3. Detach the cable from the cover (L/R) sensor cable-retaining clamp.(The diagram below shows the cover
R sensor).
4. Replace the cover sensor assembly.
5. To reassemble the unit, reverse the removal procedure.
表 4-99
No. Part name
1 Clamp
2
Cover R sensor cable
1
2
