ValueJet 1304 Service manual
4-99 AP-74109 Rev 1.1
3. Take the CR tape wire off the clamp (one point) nearby the R frame cable inlet (I/H assembly side).
4. Remove the bearer holder-retaining screw (round head spring screw M3 × 6: 2), then remove the bearer
holder.
表 4-114
No. Part name
1 CR tape wire
2 Clamp
表 4-115
No. Part name
1 Tube holder 2
2 Bearer holder and bearer
holder screw
(round head spring screw M3
×
6)
1
2
1
2
