ValueJet 1304 Service manual
AP-74109 Rev 1.1 4-104
NOTE
If the scroller is not in an horizontal position after the installation, loosen the fixing screw for scroller
height. Loosen the screw for scroller height adjustment to adjust the horizontal balance.
No. Part name
1
Take up Unit
2
Scroller receiver
3 Scroller
4 Scroller height fixing screw
5 Scroller height adjustment screw
