MUTOH ValueJet User Manual

ValueJet 1304 Service manual
AP-74109 Rev 1.1 7-4
Main board
assembly
1 Parameter backup "7.3.1 Parameter
Backup" p.7-12
2 Firmware installation "7.3.5 Firmware
Installation" p.7-21
3 Voltage input (no need for initial ink
charge)
"(1) Head Rank"
p.5-57
4 Head nozzle check "5.7.2 Head Nozzle
Check Menu" p.5-26
5 Uni-D / Bi-D Low Adjustment
Uni-D / Bi-D High Adjustment
"5.7.6 Uni-D / Bi-D
Low and High
Adjustment" p.5-36
6 Side margin adjustment "5.7.7 Side Margin
Adjustment Menu"
p.5-42
7 P_REAR sensor position adjustment "7.11.2 P_REAR
Sensor Adjustment"
p.7-48
8
Media sensor sensitivity adjustment
"7.11 Media
Sensor Sensitivity
Adjustment" p.7-45
9 Test printing "5.7.8 Test
Printing Menu" p.5-43
CR motor assembly 1 CR belt tension adjustment "7.6 CR Belt
Tension Adjustment"
p.7-35
2 Uni-D / Bi-D Low Adjustment
Uni-D / Bi-D High Adjustment
"5.7.6 Uni-D / Bi-D
Low and High
Adjustment" p.5-36
3 Side margin adjustment "5.7.7 Side Margin
Adjustment Menu"
p.5-42
4 Test printing "5.7.8 Test
Printing Menu" p.5-43
Table 7-1 Adjustment Item List (Continued)
Part replaced or
adjusted
Adjustment
order
Adjustment item Reference

MUTOH ValueJet Specifications

General

Technology	Piezo Inkjet
Ink Type	Eco-solvent ink
Print Resolution	Up to 1440 dpi
Resolution	Up to 1440 dpi
Ink Colors	CMYK, White
Media Width	64 inches
Interface	USB, Ethernet
Operating Systems	Windows
