MUTOH ValueJet User Manual

ValueJet 1304 Service manual
AP-74109 Rev 1.1 9-4
2 Lever Up Media holding
lever is turned
backward.
8. Main board
assembly may be
damaged.
Replace main board
assembly.
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
3 Media End Displayed
when media is
not set
1. Is P_EDGE sensor
assembly cable at
the head section
connected
correctly?
Securely connect it to
CR board assembly
connector J211.
"4.10.1
Replacing CR
Board
Assembly"
p.4-91
2. Is P_REAR sensor
assembly under
media guide R
connected
correctly?
Securely connect it to
main board assembly
connector J114.
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
3. Check sensor
sensitivity from
"Sen 6:EdgeAD" of
self-diagnosis
function.
Adjust with main board
assembly volume
(R117, R119).
Replace P_EDGE
sensor assembly.
"7.11.1
P_EDGE
Sensor
Sensitivity
Adjustment"
p.7-45
4. CR board assembly
may be damaged.
Replace CR board
assembly.
"4.10.1
Replacing CR
Board
Assembly"
p.4-91
5. Check presence of
media from "Sen
7:Rear" of self-
diagnosis function.
When "Media End" is
displayed even if media
is set, replace P_REAR
sensor assembly.
"4.9.2
Replacing
P_REAR
Sensor
Assembly"
p.4-90
6. CR cable may be
broken.
Replace CR cable. "4.10.3
Replacing CR
Tape Wire"
p.4-97
7. Main board
assembly may be
damaged.
Replace main board
assembly.
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
Table 9-2 Events and Check Items for Operation Status Messages (Continued)
No. Message Event/
symptom
Check item Action Reference
