MUTOH ValueJet User Manual

ValueJet 1304 Service manual
9-21 AP-74109 Rev 1.1
10 E075Err Head
Cable
Abnormal
condition in
head cable or
head
thermistor.
1. Check connection
of head cable
connectors on CR
board assembly side
and head side.
• Is head cable
inserted obliquely?
• Is it locked
securely?
Reconnect head cable. "4.6.1
Replacing
Print Head"
p.4-61
"4.10.1
Replacing CR
Board
Assembly"
p.4-91
2. Is head cable
broken?
Replace head cable. "4.6.1
Replacing
Print Head"
p.4-61
"4.10.1
Replacing CR
Board
Assembly"
p.4-91
3. Head thermistor
may be faulty.
Replace Print head
assembly.
"4.6.1
Replacing
Print Head"
p.4-61
11 E 076 error
pre-heater
system
Abnormal
condition in
pre-heater
system
(thermistor,
heater).
Disconnection of
connector, wrong
wiring, or heater
malfunction of
thermistor and heater
may be occurred.
1. Reconnect
connector of
thermistor and
heater.
2. Check connection
of board section.
3. Replace heater.
"4.4.4
Replacing
Heater and
Thermistor
Assembly"
p.4-49
"4.3
Replacement
of Board Base
Section
Components
" p.4-23
12 E077Err Platen
Heat
Abnormal
condition in
platen heater
system
(thermistor,
heater).
Disconnection of
connector, wrong
wiring, or heater
malfunction of
thermistor and heater
may be occurred.
1. Reconnect
connector of
thermistor and
heater.
2. Check connection
of board section.
3. Replace heater.
"4.4.4
Replacing
Heater and
Thermistor
Assembly"
p.4-49
"4.3
Replacement
of Board Base
Section
Components
" p.4-23
Table 9-5 Symptoms and Check Items for Mechanical Serious Errors (Continued)
No. Message Event/
symptom
Check item Action Reference

MUTOH ValueJet Specifications

General

Technology	Piezo Inkjet
Ink Type	Eco-solvent ink
Print Resolution	Up to 1440 dpi
Resolution	Up to 1440 dpi
Ink Colors	CMYK, White
Media Width	64 inches
Interface	USB, Ethernet
Operating Systems	Windows
