ValueJet 1304 Service manual
9-23 AP-74109 Rev 1.1
16 E 081 error
CR origin
CR_HP
detection is not
possible.
1. Check CR_HP
sensor from "Sen1:
CR Origin" of self-
diagnosis function.
• Check connection
of CR_HP sensor
cable assembly
connector.
"5.5.4
Sensor
Menu" p.5-15
2. CR_HP sensor may
be damaged.
• Replace CR_HP
sensor.
"4.5.2
Replacing CR
Origin Point
Sensor" p.4-
52
3. Main board
assembly may be
damaged.
• Replace main board
assembly.
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
17 E 082 error
wiper sensor
Abnormal
condition in
wiper sensor.
•Wiper sensor
assembly may be
faulty.
• Maintenance
assembly may be
damaged.
• Main board
assembly may be
faulty.
1. Check connection
of wiper sensor
connector.
2. Replace wiper
sensor.
3. Replace wiper
origin cable
assembly.
4. Replace pump cap
assembly.
5. Replace main board
assembly.
"4.7.3
Replacing
Cleaner Head
(Cleaning
Wiper)" p.4-
77
"4.3
Replacement
of Board Base
Section
Components
" p.4-23
18 E084Err Head
Dist.
Installed head
is incorrect.
Installed head is not
manufactured by other
vendor.
Replace head. "4.6.1
Replacing
Print Head"
p.4-61
19 E 085 error
head overheat
Abnormal
condition in
head driver.
Main board assembly
may be damaged.
Replace main board
assembly.
"4.3
Replacement
of Board Base
Section
Components
" p.4-23
20 E 086 error
head OVP
Abnormal
condition in
head driver.
Head or head cable may
be damaged.
1. Check connection
of head cable.
2. Replace head.
"4.6
Replacement
of Head
Section
Components
" p.4-61
Table 9-5 Symptoms and Check Items for Mechanical Serious Errors (Continued)
No. Message Event/
symptom
Check item Action Reference
