MUTOH ValueJet User Manual

ValueJet 1304 Service manual
9-27 AP-74109 Rev 1.1
16 Boot Transfer
failed
Opening seq.
failed
Opening
sequence of
boot code
transfer failed.
• Check connection
between control
board and main
board.
• Check if the green
LED on control
board is lit.
• Check if the red
LED on control
board is blinking.
• Reconnect control
board and main
board. Otherwise,
replace the cable
connecting control
board and main
board.
• If the green LED on
control board is off
after the power is
turned on, replace
the control board.
• If the red LED is
blinking and there is
no problem at
connection between
control board and
main board, try to
reinstall firmware.
• If the red LED is
off, perform the
following
procedures.
1. Turn off the power,
then switch the DIP
switch as follows:
1: ON
2: ON
3: ON
4: OFF
2. Start the board
manager mode.
3. Reinstall firmware.
4. Turn off the power,
then switch the DIP
switch as follows:
1: ON
2: OFF
3: ON
4: OFF
5. Turn on the power,
then check if the red
LED is blinking.
"4.3.4
Replacing
HEATER
CONT board
assembly"
p.4-30
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
"7.3
Working with
MUTOH
Maintenance
Engineer
Assistant"
p.7-8
"7.4
Working with
MUTOH
Service
Assistance"
p.3-30
Table 9-6 Error Messages During File Transmission (Continued)
No. Message Event/
symptom
Check item Action Reference
