MUTOH ValueJet User Manual

ValueJet 1304 Service manual
AP-74109 Rev 1.1 9-64
6
7
Some data are not
printed (missing).
1. Printer driver may be
defective.
Update printer driver. Operation
Manual
Some data change to
garbage.
2. Program ROM may be
defective.
Update firmware. "7.3.5
Firmware
Installation"
p.7-21
3. Is T fence
contaminated or worn
out?
• If grease or dust collect:
Wipe fence with a dry
cloth.
• If ink deposit presents:
Wipe it off with cloth
dampened with neutral
detergent.
• If contamination or
deposit is too heavy:
Replace T fence.
"4.5.4
Replacing T
Fence" p.4-55
4. Check “CR Encoder”
from “Test5: Encoder”
of “Check2: Test” of
self-diagnosis
function.
• Move carriage in both
directions and check the
numeral value on LCD.
If the numeral value
doesn't change normally,
check main board
assembly connector J12.
• Replace T fence.
• Replace CR motor
assembly.
• Replace CR board
assembly.
• Replace CR cable.
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
"4.5.4
Replacing T
Fence" p.4-55
"4.5.1 CR
Motor
Assembly"
p.4-51
"4.10.1
Replacing CR
Board
Assembly"
p.4-91
"4.10.3
Replacing CR
Tape Wire"
p.4-97
5. Main board assembly
may be
malfunctioning.
Replace main board
assembly.
"4.3.3
Replacing
Main Board
Assembly"
p.4-29
Table 9-11 Symptoms, Check Items, and Actions for Online Function Problems (Continued)
No. Event/symptom Check item Action Reference

MUTOH ValueJet Specifications

General

Technology	Piezo Inkjet
Ink Type	Eco-solvent ink
Print Resolution	Up to 1440 dpi
Resolution	Up to 1440 dpi
Ink Colors	CMYK, White
Media Width	64 inches
Interface	USB, Ethernet
Operating Systems	Windows
