ValueJet 1304 Service manual
AP-74109 Rev 1.1 4-20
NOTE
There are two hole to attach the scroller receiver on the frame side. See the right of illustration below
for the hole for VJ-1304. Make sure that the part is attached to the appropriate position.
No. Part name
1
Attachment hole for scroller receiver of VJ-1304
2
Screw holes for fixing scroller receiver
1
2
