MUTOH Valuevet VJ-628X User Manual

2.2 Troubleshooting with Error Messages VJ628XE-M-00
2.2.1 Operation Status 16
3 End of Roll Media has run out. 1. Is the cable of P Rear Sensor placed
under Paper guide R securely
connected?
Securely connect it. "Electric Wiring Diagram
2. Check if there is paper in “Sen : Rear” in
the self-diagnosis function.
If “No media” is displayed even when paper is
loaded, check the item 5.
"5.4.4Sensor Menu
3. P Rear Sensor may need adjustment or it
may be damaged.
Adjust P Rear Sensor.
If the same error continues to be displayed,
replace P Rear Sensor.
"5.6.1Rear/ Edge Sensor Adjustment
"3.6.14Replacing P_REAR Sensor
4. MAIN board may be damaged. Replace MAIN board. "3.5.10Replacing MAIN Board
4 No media Media is not loaded. 1. Check if there is paper in “Sen. : Rear” in
the self-diagnosis function.
If “No media” is displayed even when paper is
loaded, replace P Rear Sensor.
"5.6.1Rear/ Edge Sensor Adjustment
"3.6.14Replacing P_REAR Sensor
2. Does the media in use have low
reflectance?
Instruct the user that media with low
reflectance cannot be used.
-
3. Is the cable of P Rear Sensor placed
under Paper guide R securely
connected?
Securely connect it.
"Electric Wiring Diagram
4. P Rear Sensor may need adjustment or it
may be damaged.
Adjust P_REAR sensor.
If the same error continues to be displayed,
replace P_REAR sensor.
"5.6.1Rear/ Edge Sensor Adjustment
"3.6.14Replacing P_REAR Sensor
5. MAIN board may be damaged. Replace MAIN board. "3.5.10Replacing MAIN Board
Table 2-1 Events and Check Items for Operation Status Messages (Continued)
No. Message Event/symptom Check item Action Reference
