3.10.5 Replacing Wiper Solenoid 162
3.10 Replacing Maintenance VJ628XE-M-00
8 Remove the spring, washer and spring pin
from plunger.
A : Plunger
B : Spring pin
C : Spring
D : Washer
Spring, washer and spring pin will be
reused. Take care not to lose them.
9 Replace it with new Wiper Solenoid.
10 To reassemble unit, reverse the removal
procedure.
A
B
C
D
