4.3.15 Reffering Adjustment Parameter 222
4.3 Working with MUTOH Service Assistance Software VJ628XE-M-00
(2) Acquiring Adjustment parameter from printer to reference
1 Click on [Adjust Parameter].
2 Click [OK] on [Adjustment parameters
download] to start.
*Click [Cancel] to return to main window
without adjustment parameter
acquisition.
After clicking [OK], if any communication errors occur such as wrong IP address or
unplugged LAN cable, an error message appears. If any setting errors occur such
as inappropriate model name selection, serial number registration is not finished or
incorrect one is registered, an warning message appears.
In both cases, communication with printer shall be interrupted.
Click [OK] to return to main window.
3 When adjustment parameter
acquisition is in progress, a progress
dialog appears.
4 Adjustment parameter is displayed
under a Adjust parameter tab page after
the completion of acquisition of
Adjustment parameter from a printer.
Since a "Adjustment parameter
download" window is displayed after
that, click [OK] and it checks the listed
setup information.
5 Acquired set up information shall be
indicated under the tab named [Adjust
parameter].
To save the file as plain text, click .
*Set up information is same detail with
the one acquired in [Print setup
parameters].
"5.8Sample printing Menu
• The serial number of Printer, model name and various F/W version are
displayed.
• The contents based on an adjustment parameter are displayed.
• Adjustment parameter file shown on the window shall be saved whether tab is
switched over to others. When another parameter file is acquired or saved
parameter file is open, the detail shall be renewed.
