Self Diagnosis Function Diagram 3 VJ628XE-M-00
403P.11-403
Self Diagnosis Function Diagram 3
Init.1 : Print Num
Init.2㸸PrintInfo.
Init.3㸸ALL
Init.4㸸CR Motor
Init.5㸸PF Motor
Init.6㸸HeadUnit
Init.7㸸Wiper
Init.8㸸Pump
Init.9㸸CPump1
Init.10㸸CPump2
Init.11㸸Cutter
Init.12㸸UnlockPos.
Init.13㸸WasteInk
Mainte. 1 : Indication
Mainte.2 : InitCounter
Mainte.3 : Cleaning
Mainte.4㸸Print
Mainte.5 : MediaFeed
Print Numer
CR Motor
T.CR Motor
PF Motor
T.PF Motor
Pump
T.Pump
CPump1
T.CPump1
CPump2
T.CPump2
Fire A
Fire B
Fire C
Fire D
Fire E
Fire F
Fire G
Fire H
T.Fire Aࠉ
T.Fire Bࠉ
T.Fire Cࠉ
T.Fire D
T.Fire E
T.Fire F
T.Fire G
T.Fire H
Cleaning
Wiper
Wiper Sol.
CutNumber
CutterSol.
UnlockPos.
Waste Ink
Indication㸯㸸Mainte.
Indication㸰㸸Print
Indication㸱㸸Ope.Time
Print1㸸Num
Print2㸸Area
Print3㸸Effect
Total
Noramal
Diag
Mainte.
Check1㸸Tset
Check2㸸Charge
Check3㸸Adjustment
Check4㸸Cleaning
Check5㸸Print
Check6㸸Parameter
Check7㸸Servo
Check8㸸Endurance
Check9㸸MediaFeed
Check10㸸MediaInitial
Check11㸸Heater
Check12㸸Speed Mode
refer to Self Diagnosis Function Diagram (1/3)
refer to Self Diagnosis Function Diagram (2/3)
Servo1㸸320 cpsࠉCW
Servo2㸸320 cpsࠉCCW
Servo3㸸400cpsࠉ CW
Servo4㸸400cpsࠉ CCW
Life1㸸CR Motor
Life2㸸PF Motorࠉࠉࠉࠉࠉࠉࠉࠉࠉࠉࠉࠉ
Life3㸸Cutter
Life4㸸Pump
Life5㸸CPump
Life6㸸Head Lock
Life7㸸Wiper
Life8㸸Nozzle
Life9㸸Total Life
Life10㸸Check
Top&Width
Width
Off
Heater1㸸Sensor
Heater2㸸Check
Normal
Low
GP
GI
GLPF
PWM Scale
ȰC
Ver. 1.00
