2.3 Troubleshooting Without Error Messages VJ628XE-M-00
2.3.6 Other Problems 56
6 Ink spills around X rail 1. Tubes of Flushing box or Maintenance Assy may be
disengaged.
• Check if Tubes of Flushing box or
Maintenance Assy are disengaged.
• Replace Maintenance Assy.
• Replace Flushing box.
3.10 Replacing Maintenance
2. Is Waste fluid tube bent? Make sure that approximately 160mm of Waste
fluid tube comes out downward from Leg holder
base (exploded view A-1).
-
3. Is Waste fluid tube clogged? Replace Waste fluid tube.
-
4. Ink tube may be disconnected Replace Ink tube.
"3.9.4Replacing Ink Tube
5. CR board may be damaged. Replace CR board.
"3.8.4Replacing CR Board
6. Head may be damaged. Replace Head.
3.8.15 Replacing Head
7. MAIN board may be damaged. Replace MAIN board.
"3.5.10Replacing MAIN Board
Table 2-11 Symptoms, Check Items, And Actions(Continued)
No. Symptom Check item Action Reference
