3.6.1 Replacing CR Motor 92
3.6 Replacing Y Rail part VJ628XE-M-00
11 After adjusting, apply Thread Locker to
Tension adjusting screw.
A : Pan head small screwM4ｘ30
B : applying point
12 To reassemble unit, reverse the removal
procedure.
13 Perform various adjustments.
4.2 Adjustment Item
To Next Page
