SleeperFeatures

FloorCovering

ThestandardoorcoveringfortheInternational

and

™

Seriessleepercompartmentisadurablerubbermatwith

cushionedinsulationundertherubbermat.

AnoptionalcarpetinsertisavailableonselectInternational

andRH

™

Seriessleepermodels.Itcaneasilyberemovedfor

cleaning.

SleeperFan

Theoptionalsleepercompartmentfanismountedonthe

headlinerjustbehindthepassengerseat.Thesleeperfanis

equippedwithapush-buttonswitchforturningthefanON,OFF,

andadjustingthefanspeeds.

127
