Operation

Intellipark

™

LEDOperation

TheIntellipark

™

LEDslettheoperatorknowwhenthetractorand

/ortrailerbrakesareengagedordisengaged.

StartupCheck,LEDS

illuminatefor3Seconds

TrailerParkingBrakes

Engaged

TractorParkingBrakes

Engaged

TrailerParkingBrakes

Engaged

TractorParkingBrakes

Disengaged

TrailerParkingBrakes

Disengaged

TractorParkingBrakes

Engaged

TrailerParkingBrakes

Disengaged

TractorParkingBrakes

Disengaged

TheLEDswillalsoturnoff

whentheparkingbrakes

areengagedwiththe

ignitionintheKeyOFF

position.

WARNING

Topreventpersonalinjuryand/ordeath,or

damagetoproperty,theoperatorshouldNOT

DRIVETHEVEHICLEwhenanycombinationof

Intellipark

™

LEDSareblinking.AblinkingLED

indicatesthatIntellipark

™

hasfaultedandthe

vehiclemaynothaveparkingbrakesavailable

whenneeded.
