Controls/Features

GaugeNameGaugeDisplays

RearRearAxle

Temperature

Temperatureofthe

lastaxleonthetractor

portionofthevehicle.

TransmissionOil

Temperature

Temperatureofthe

transmissionuid.

Voltmeter

Amountofvoltage

outputfromthebattery.

Switches

Thereare40differentoptionsforswitches;upto26canbe

locatedinthecenterinstrumentpanel.Locationsofthese

switcheswillvarydependingontheoptionsinstalled.Blank

coverplateswillbeusedinspacesthatdonothaveswitches

installedatthoselocations.

SwitchIconDescription

EngineBrake

ON/OFF

Activatesordeactivatesthe

enginebrake.

EngineBrake

Selector

Athree-positionswitchthat

selectsamountofengine

braking(1=Low,2=Medium,

3=High).

Traction

Disabled

Deactivates/activatestraction

control.

PTO

Usedwhenvehiclehassingle

PTOoption.
