MaintenanceIntervalsandSpecications
TypicalLuggageCompartmentFusePanelLayout
TypicalUnder-HoodPowerDistributionModule(PDM)
FusePanelLayout
NOTE:Thecontentsofthismanualwillbegeneralandmay
notreectthemostcurrentvehicleconguration.Ifthe
contentofthismanualdoesnotprovidetheexplanation
neededtounderstandoroperatethefeatureyouareusing,
pleasecontactyourlocalInternationaldealerorreferto
International
®
ServicePortal
SM
forthemostuptodate
information.
OncertainInternational
®
LT
®
andRH
™
Seriesmodels,youcan
ndaPowerDistributionModule(PDM)underthehoodon
thedriver-side.Itismountedontheaircleanerbracketand
isimmediatelyunderneaththecowlpanel.Seethefollowing
illustrationaboutthelocationoftheunder-hoodPDM.
1.Under-HoodPowerDistributionModule(PDM)
IfyoucannotndthePDMinthislocation,itmeansthatyour
vehiclehasin-linefusesinsteadofaPDMfusepanel.
Thefollowingillustrationsshowtwodifferentlayoutsofthefuse
panelsintheunder-hoodPDM.
CAUTION
Topreventelectricalcomponentdamage,when
replacingafuse,alwaysuseonewiththesame
amprating.
292
