InspectionGuide

RearofCab

1.Airsuspension(2)

2.T orsionbar

3.Heightcontrolvalve

4.Shockabsorber(2)

WARNING

Topreventpersonalinjuryand/ordeath,or

damagetoproperty,maintainadequateclearance

betweenallpartsoftheexhaustsystemandall

hoses,wiresandlinesforenginecooling,brake

system,fuelsystem,powersteeringsystemand

electricalsystem.Heatdamagetohoses,wires

maycausevehiclemalfunction.

WARNING

Topreventpersonalinjuryand/ordeath,or

damagetoproperty,checkforairleaks,loose

components,anddamagetoairbagwithinthe

cabandsuspensionsystems.
