Navistar International LT Series User Manual

Operation
TheMaxwell
®
EngineStartModule(ESM)isanenginestarting
aiddesignedtostartthevehiclewithouttheuseofthemain
vehiclebatteries.TheESMislocatednexttothevehicle
batteriesbutsuppliespoweronlytothevehiclestarter.The
vehiclewillbestartedusingthepowerstoredintheESM
insteadofbatterypower.Thisallowsusageofvehiclefeatures
poweredbythemainvehiclebatterieswhiletheengineisnot
running.TheESMeliminatestheriskofdrainingthebatteries
tothepointofanenginenostartcondition.Indicatorlamps
andapush-to-testbuttonarelocatedonthetopoftheESM.T o
activatetheindicatorlamps,pressthepush-to-testbuttonand
release.Theindicatorswillilluminateand/orash(depending
onstatus)for10seconds.Holdingthepush-to-testbuttonfor
12secondswillresetthemodulecomputer.
Refertothefollowingtableformoreinformationontheindicator
lamps:
GREENLampREDLampDescription
SolidlampNotIlluminatedReadytoStart
FlashingLampNotIlluminated
Charging:WaitApprox.
15Minutes
NotIlluminatedFlashingStuckPush-to-T estButton
NotIlluminated
Solid
Illumination
InternalError:HoldTest
Buttonfor10Seconds
FlashingLamp
Solid
Illumination
RefertoManufacturer’s
OperationManual
NOTE:Refertowww.maxwell.comformoreinformationon
theMaxwell
®
enginestartmodule.
CircuitBreakers,FusesandFusibleLinks
WARNING
Topreventpersonalinjuryand/ordeath,or
damagetoproperty,donotoperatevehicleif
thereislossofsteeringorsuspension,which
couldcauselossofvehiclecontrol.,donot
increasesizeoffuseorcircuitbreakerorchange
typeofbreakersuppliedwithyourtruck,asthis
couldcausewiringtooverheatandpossibly
burn.Electricalcircuitsaredesignedwitha
particularwiregaugetomeetthefuseandcircuit
breakercurrentrating.
1.Fuseblockaccesspaneltab
158
