Navistar International LT Series User Manual

Operation
WARNING
Topreventinjuryand/ordeath,ordamage
toproperty,alwayshaveenginestartmodule
servicedbyaqualiedtechnician.TheESM
isanextremelyhighvoltagemoduleand
servicingshouldonlybeperformedbyqualied
personnelusingnecessarysafetyprocedures
andequipment.
WARNING
Topreventpersonalinjuryand/ordeath,
ordamagetoproperty,donothandlethe
enginestartmodulewhilefullycharged,always
dischargepriortoremovaland/orhandling.
Theenginestartmodulepowerterminalcan
produceanextremearcinghazard.Referto
theappropriateservicemanualfordetailed
instructionsondischargeprocedure.
WARNING
Topreventpersonalinjuryand/ordeath,or
damagetoproperty,DONOTcheckmodule
conditionbyshorting(ashing)acrossterminals.
WARNING
Topreventpersonalinjuryand/ordeath,or
damagetoproperty,donotconnectbattery
cablestothestarterpositiveterminal,thiscan
causeabatteryshortand/orelectricalarcing.
1.ESMbatterypositiveterminal
2.ESMstarterpositiveterminal
3.Push-to-T estbutton
4.Indicatorlamp
5.ESMbatterynegativeterminal
