SleeperFeatures

SECTION5—SLEEPERFEATURES

Introduction

GeneralInformation

Therearetwotrimversionsofsleepersavailable:

•International

andRH

™

ClassicSeries

•International

andRH

™

DiamondSeries

TheBlackCherryinteriorcanonlybeaddedtotheDiamond

interiortrim.

TheInternational

Seriessleepercompartmentcomesintwo

sizes:

•56-in(142cm)shortsleepers

•73-in(185cm)longsleepers

TheRH

™

Seriessleepercompartmentcomesonlyinthesize

56-in(142cm)shortsleepers.

MainFeatures

Thesleepercompartmentsaredesignedtoaccommodate

differentneeds,andyoursleepermayormaynotbeequipped

withallthefeatureslistedinthissection.

CommonfeaturesontheInternational

andRH

™

Series56-in

(142cm)shortsleepermodels.

0000413722

6 7 8 6

56-inShortSleeperCab

1.Airlinecabinet

2.Rearwardrobecabinet

3.Controlpanel

4.Ductworkvent

5.Cupholdersandstoragetray

6.Speaker

7.Lowerbunk

8.Underbunkstoragearea

103
