MaintenanceInstructions

CAUTION

Topreventcomponentdamage,becausehot

coolantexpands,donotoverllthecooling

systemwhentoppingoffthedeaerationtank.

OnlylltotheMAXllline.

Forthetop-offprocedurepleaseperformthefollowing

instructions:

1.Allowenginetocool.

2.Locatethedeaerationtank.

3.Removeventedllcap.

4.Usingthecorrectmixture,carefullypourcoolantintothe

deaerationtankuntilcoolantreachestheCOLDMAXline.

DonotexceedtheMAXline.

5.Installtheventedllcap.

Top-OffInstructionsforCummins

X15Engines

ForvehicleswithCummins

X15engines,seethefollowing

instructionsontoppingoffthecoolingsystem.

TypicalX15DeaerationTank

1.COLDMINandCOLDMAXlines

2.Ventedllcap

3.Deaerationtank

249
