Navistar International LT Series - Auto Start; Stop System Battery Cables: International RH Vehicles Only; High Current Relay

To Next Page

To Previous Page

MaintenanceInstructions

AutoStart/StopSystemBatteryCables:International

™

VehiclesOnly

CAUTION

Topreventpropertydamage,ifequippedwiththe

autostart/stopfeature,thebatteriesmustbe

hookedupexactlyasshownintheillustration

below.

Whenequippedwiththeautostart/stopfeature,thebattery

cablesrequireaspeciccongurationforhookingupthebattery.

HighCurrentRelay

CAUTION

Topreventpropertydamage,whenservicing

theisolationbattery,besurethatallcables

areconnectedcorrectlytopreventdamage

tothehighcurrentrelayandotherelectrical

components.

1.HighCurrentRelay

2.BatteryBox(Back)

Themainvehicle’sbatteryboxisequippedwithahighcurrent

relaytoisolateonebatteryduringtheautostart/stopcrank

operationandtostabilizepowertoelectricalsystemcontrollers.

238
