SleeperFeatures

Cabinets/Storage

GeneralInformation

WARNING

Topreventpersonalinjuryand/ordeath,or

damagetoproperty,alwaysremoveallloose

itemsfromtheinteriorandstoreappropriately

whenvehicleisinmotion.Fallingitemscanbea

distractiontothedriver,oraprojectilecancause

anaccident.

NOTE:Thefollowingwilldescribeandillustratethe

standardcabinetsandtheirstoragefunctionsforthe

International

Serieslongsleeper.Yourvehiclemaynot

haveallofthesefeatures.

Thesleepercompartmentisdesignedtoaccommodate

severaldifferenttypesofcabinetcongurationstotall

needs.

0000413660

1.Airlinecabinet

2.T owerwardrobe

3.Optionaldressercabinetoroptionalrefrigeratorcabinet

121
