ModelDescription

SECTION2—MODELDESCRIPTION

Introduction

ThisoperatormanualcoverstheInternational

andRH

™

Seriesmodels.Illustrationsinthismanualareusedforreference

onlyandmaydifferslightlyfromtheactualvehicle.However,

keycomponentsaddressedinthemanualarerepresented

asaccuratelyaspossible.Modelscoveredareshownonthe

followingpages.

AvailableModels

NOTE:Somevehiclesmaybeequippedwithadditionalaero

equipmentsuchasairfairingsandcabsideextendersto

helpincreasevehicleaerodynamicsandfueleconomy.

4x2Lo-RiseDayCab

4x2DayCabwithAirFairingandCabSideExtenders
